• MikeMorenoDSP

    Download: http://gum.co/lira-8
    Source Code (GitHub): https://github.com/MikeMorenoDSP/LIRA-8

    The Lira•8 is a digital attempt at emulating SOMA Lab's Lyra-8 signal flow and sound.
    The Lyra 8 is a Russian drone synthesizer with 8 tunable voices each, FM, dual delay, hyper LFO and distortion.
    It makes it optimal for drones, ambient landscapes, outer space sounds, etc.

    Disclaimer: The Lira•8 project is not affiliated and does not represent SOMA laboratories.

    posted in patch~ read more
  • MikeMorenoDSP

    @Eeight Awesome thanks for the pin! :)

    posted in news read more
  • MikeMorenoDSP

    Join the Pure Data Discord Server!
    Link: https://discord.gg/aNd8RrT

    I did a small composition for promoting the discord server. The patch is available on the #general chat.

    Discord is an instant messaging application that allows users to have multiple chat rooms and voice chat rooms.
    Imagine this forum only in chat form. This enables users to discuss multiple topics on different dedicated text channels and do live performances on voice chat.

    Hope you join us!

    posted in news read more
  • MikeMorenoDSP

    Hello!
    I’ve been working on a sound installation that records your voice on a public space and then plays it back on a FM radio transmitter.

    Since then, I’ve been searching for different voice activity detection (VAD) algorithms for Pure Data and found very little.
    So far, my best lead is this article: https://medium.com/linagoralabs/voice-activity-detection-for-voice-user-interface-2d4bb5600ee3

    So I thought I’d share my simple algorithm for VAD in public spaces and ask:

    How would you approach detecting voice activity in real-time in a public space with a lot of noises and non-voice signals?

    Here's my patch: VAD.pd

    posted in technical issues read more
  • MikeMorenoDSP

    Hello! Kind of late to this thread.
    Thought I might post my attempt on doing a low pass gate using vanilla objects.
    Replaced threshold using >=~ from the heavy library.
    And used lop~ since it has similar curves like the vactrol, only fixed attack and release.
    Finally, I used a resonant-lowpass filter from the heavy library.
    Lots of great info here, thanks guys.
    LPG.pd

    posted in technical issues read more
  • MikeMorenoDSP

    @60hz Never too late! Thanks so much! :D

    posted in technical issues read more
  • MikeMorenoDSP

    Hello,
    Just thought I would share my attempt on replicating the sounds of Radiohead's Idioteque using only synthesis on Pure data vanilla:
    Here's the result:
    https://patchstorage.com/radioheads-idiotique-on-pd/

    posted in output~ read more
  • MikeMorenoDSP

    Patch available here, under the Instruments folder:
    https://github.com/MikeMorenoAudio/pd-mkmr

    My latest effort to create an instrument that somewhat resembles a piano.

    Basically it's a Karplus-Strong string with a fixed lop~ at 6kHz with a 240 filtered noise impulse and a filtered saw impulse.

    DEMO

    posted in patch~ read more
  • MikeMorenoDSP

    Like this?
    Here I'm using a phasor~ to generate a sinewave and then using samphold~ to create consistent steps for the LFO.
    But, now that you mention semi-random steps, then you could have a second LFO in a different frequency controlling the samphold~ output.
    Using a source like noise~ could achieve those semi-random steps:

    posted in technical issues read more
  • MikeMorenoDSP

    Algorithmic Composition // Catarina

    A 100% synthesized algorithmic composition made using Pure Data Vanilla 0.49-1. Made for the upcoming Muff Wiggler Discord Collective Album.

    Instruments and sounds used are part of my library: pd-mkmr
    https://github.com/MikeMorenoAudio/pd-mkmr

    Patch available here: https://patchstorage.com/algorithmic-composition-catarina/

    Full version on Youtube

    posted in output~ read more
  • MikeMorenoDSP

    Is using pd-extended really necessary? Try the lastest vanilla distribution.
    I have a slight suspicion it only works with vanilla since the spout for pd/Gem was released in 2016 and the last pd-extended release was in 2013.
    Installing GEM on vanilla is way easier now, you just need to download it via deken and write "Gem" on your startup libraries.

    posted in pixel# read more
  • MikeMorenoDSP

    Hello pd-fellas, 👋
    Here's a new abstraction I made based on Mike Moser-Booth's [curve.mmb~] abstraction from the mmb library.
    This version allows you to draw curved ramps into arrays. These can then be used as envelopes, wavetables, GUIs, waveshapers, etc.
    ––
    Download (03-Envelopes folder):
    https://github.com/MikeMorenoAudio/pd-mkmr

    DEMO

    posted in abstract~ read more
  • MikeMorenoDSP

    Hello everyone, thanks for the mention @Jona!
    @MeneerJansen That TR-808 snare is for a client, so I'm unable to share it.
    On the other hand, here's a more basic TR-808 kick and snare, it has the basic blocks for it: kick-and-snare.pd

    • One oscillator with two harmonics, each harmonic has its own envelope curve and one is more snappier than the other.
    • A filtrated noise source with more decay time than the drum layer

    You can make it snappier by distorting the first milliseconds.
    If you know synthesizer terms you can try and emulate it better using to Adam Schenider's tutorial to make an 808 style snare.

    @ingox There is a sample being played for comparison with my synthesized version.

    posted in technical issues read more
  • MikeMorenoDSP

    @metaphysician Sure thing, ask away here or in a private chat. My discord username is Mike Moreno#1780
    [mct~] is additive synthesis using different envelope curves for each harmonic.
    [piano~] is pretty straight forward, just 3 karplus-strong operators a little bit detuned.
    I still want to make a better, more realistic piano sound, but in order to do this I need to understand how to create inharmonicity using allpass filters.
    Judging from an spectrograph of a piano sound, the upper harmonics seem to be gradually shifting from the fundamental frequency, there's even a little bit of pitch modulation. Here's a good reference using additive synthesis min 1:46

    posted in output~ read more
  • MikeMorenoDSP

    Thanks! I'll probably port it to Camomile and Heavy VST in the future.
    I also need to document this for future reference,
    Documentation and promotion is half the battle lol

    posted in output~ read more
  • MikeMorenoDSP

    [mymembrane~]
    A synthesizer focused on the creation of acoustic drum-like sounds.

    Patch available here:
    https://github.com/MikeMorenoAudio/pd-mkmr/tree/master/06-Instruments

    Demo:

    posted in output~ read more
  • MikeMorenoDSP

    Hello pd people,
    I just updated the sound engine of my physical modeled electric piano VST made using Camomile.

    Download (VST for Llnux 64, Win32, Win64 & macOS)
    https://patchstorage.com/ep-mk1/

    Video Demo

    posted in output~ read more
  • MikeMorenoDSP

    Actually makes me wonder. How do you detect the end of a cycle?
    This in order to sync the end of the cycle of my LFO2 to the start of my LFO1

    posted in technical issues read more
  • MikeMorenoDSP

    Heres an example taking example in the Aphex twin song.
    This one modulates amplitude, but you can easily change it to pitch.
    Basically the LFO1 is changing the rate of the LFO2 which is modulating the amplitude.
    Heres the patch: Ball

    posted in technical issues read more
